The ECH30 Series current transformer is compact smaller than other models with the current ratio of the transformer is small, clamshell-style terminal cover is well protected by the second terminal. With related accessories you can use Din rail mounting.
Standard Input Current: 0-300A;
High accuracy and excellent linearity;
Custom design Turns-Ratio available;
Design standards: ANSI C57.13 & IEC60044-1 & UL Recognized;
With UL Certification & CE Certification.
Current output: 5mA,10mA,20mA,33.3mA, 40mA, 50mA, 100mA, 1A, 5A...
Voltage output: 0.25V, 0.333V, 0.5V, 1V, 2V,5V...
Monitoring and protection;
Energy and sub-metering products;
Instruments and sensors;
Excellent linearity over the whole range;
Fully RoHS compliant.
